BenQ AK700ST 4K Golf Simulator Projector
$2,899.00
The AK700ST is a 4K laser projector with automatic screen fit and a motorized zoom lens. Point it at your screen, and it finds the edges and aligns the image by itself. If you adjust your screen or enclosure later, recalibration takes seconds. The motorized zoom means you can fine-tune the image size from a distance rather than physically moving the projector.
This is the projector that combines 4K resolution, laser reliability, and hands-off setup in one package. No lamp replacements. No manual alignment on your knees. Set it up, and it handles itself.
At a Glance:
Price $2,899
Resolution 4K UHD
Brightness 4,000 lumens
Light Source Laser — no lamp replacement needed
Throw Type Short-throw — sits 6–8 ft from a standard screen
Auto Screen Fit Yes — detects and aligns automatically
Motorized Zoom Yes — 1.2x, adjust image size remotely
HDMI Inputs 2 × HDMI
What You're Getting
The AK700ST is the one you choose when you want to stop thinking about the projector and just play golf. Auto screen fit handles the image alignment when you mount it. The motorized zoom adjusts the image size from wherever you’re standing — no ladder, no repositioning. And the 4K laser keeps that image sharp and consistent for the long term without lamp maintenance.
Once it’s installed, it stays out of your way. That’s what the AK700ST is built for.
Key Specs
| SPEC | DETAIL |
|---|---|
| Resolution | 4K UHD (3840 × 2160) — 8.3 million pixels |
| Brightness | 4,000 ANSI lumens |
| Throw Ratio | 0.69–0.83:1 |
| Zoom | 1.2x motorized optical zoom |
| Light Source | Laser — no lamp replacement |
| Light Source Life | 20,000 hours |
| Color Accuracy | 95% Rec.709 |
| Auto Screen Fit | Yes — supports 16:9, 16:10, 4:3, 1:1 |
| HDR Support | HDR10, HLG |
| Connections | HDMI 2.0, USB-C |
| Dust Protection | IP5X sealed optical engine |
| Weight | 11 lbs |
| Dimensions | 17 × 14 × 7 in |
Installation
| Measurement | Spec | Notes |
|---|---|---|
| Throw ratio | 0.69–0.83:1 | Short-throw — stays out of the swing zone |
| Distance for 120″ screen | Approx. 6–8 ft | Motorized zoom covers this range without moving the projector |
| Screen size range | Up to 200″ diagonal | Standard simulator screen sizes |
| Auto Screen Fit | Yes — automatic | Detects screen edges and aligns the image |
| Motorized zoom | Yes — 1.2x | Resize the image without moving the projector |
| Mounting | Ceiling or shelf | Standard projector mount — not included |
Connections
- 2 × HDMI 2.0 — connect your PC to one port
- USB-C — supports HDR10 and HLG content
- 5mm audio out
AK700ST vs AH700ST — The Key Difference
| AH700ST ($2,299) | AK700ST ($2,899) | |
|---|---|---|
| Resolution | 1080p | 4K UHD — sharper on large screens |
| Brightness | 4,000 lumens | 4,000 lumens |
| Auto screen fit | Yes | Yes |
| Motorized zoom | No | Yes — 1.2x, adjust image size remotely |
| Light source | Laser | Laser |
| Choose this if… | 1080p is enough | You want 4K image quality and zoom convenience |
What Else You'll Need
The AK700ST is the projector. To build a complete simulator setup around it you’ll also need:
| COMPONENT | WHAT IT DOES | FIND IT AT PORTERSGOLF |
|---|---|---|
| Launch monitor | Tracks ball and club data | Launch Monitors |
| Enclosure / frame | Contains shots, holds screen | Carl’s Place DIY Enclosure |
| Impact screen | Ball target and projection surface | Impact Screens |
| Hitting mat | Turf surface to swing from | Hitting Mats |
| Simulator PC | Runs the software | Computers & Monitors |
💡 Not sure if this projector fits your room? Email your room dimensions and screen size to [email protected] and we’ll confirm the right throw distance and mounting position before you order.
| Weight | 11 lbs |
|---|---|
| Dimensions | 17 × 14 × 7 in |
